Specifications
200' (60m) depth rating
Compatible with DL system lens ports
Controls are provided for all important camera controls; Controls are not provided for?LCD panel illumination button. Depth-of-field preview button.?Dioptric adjustment knob.?Multi function lock switch?
1/4-20 thread base mounts with 3.5 spacing
Near neutral buoyancy in fresh water
Actual buoyancy varies depending on choice of lens and port
4.7 lb (2.1 kg)
9.2 x 7.1 x 6.5 (234 x 180 x 165 mm)
Vacuum valve included (pump sold separately)
Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provides automatic exposure with compatible Ikelite DS strobes
ABS-PC construction is fundamentally corrosion-resistant
Made in the USA; Individually inspected for fit and water pressure tested to depth
2?year limited warranty
In the Box
Housing
Rear O-ring # 0132.59 (installed)
Front O-ring # 0132.45 (installed)
Zoom Gear Retainer # 75900 (installed)
Port Hole Cover # 0200.92 (installed)
Waterproof Bulkhead Cap # 9104.7 (installed)
Base with Left-Hand Quick Release Handle # 4077.67 (installed)
Tool for Zoom Gear Retainer # 0945.06
.050?Hex Key # 0945.11
1/16 Hex Key # 0945.16
Silicone Lubricant? 1cc tube
?
